Grandstream GRP2603P 3-line Essential IP Phone


Brands Grandstream
Model: Grandstream GRP2603P
Availability: In Stock
Part No: GRP2603p

The Grandstream GRP2603P is an essential 2-line model designed with zero touch provisioning for mass deployment and easy management. It features a sleek design and a suite of next generation features including, 5-way voice conferencing to maximize productivity, full HD audio on both the speaker and handset to allow users to communicate with the utmost clarity, EHS support for Plantronics, Jabra, and Sennheiser headsets and multi-language support. The GRP series includes carrier-grade security features to provide enterprise-level security, including secure boot, dual firmware images and encrypted data storage.

Grandstream GRP2603P Key Features
3 lines, 6 SIP accounts, up to 3 call appearances
Supported by GDMS which provides a centralized interface to configure, provision, manage and monitor Grandstream devices
Full-duplex speakerphone with HD audio to maximize audio quality and clarity
Equipped with noise shield technology to minimize background noise
Electronic Hook Switch (EHS) support for Plantronics, Jabra, and Sennheiser headsets
Supports 5-way audio conferencing for easy conference calls
Enterprise-level protection including secure boot, dual firmware images, and encrypted data storage
Swappable faceplate to allow for easy logo customization
Dual switched autosensing 10/100/1000 Mbps Gigabit Ethernet ports

ر.س200.00

Grandstream GRP2603P Technical Specifications
Protocols/Standards

SIP RFC3261, TCP/IP/UDP, RTP/RTCP, RTCP-XR, HTTP/HTTPS, ARP, ICMP, DNS(A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP, LDAP, TR069, SNMP, 802.1x, TLS, SRTP, IPv6
Network Interfaces

Dual switched auto-sensing 10/100/1000 Mbps Ethernet ports
Graphic Display

132 x 64 (2.48’’) backlit graphical LCD display
Feature Keys

3 line keys with dual-colour LED and support for 4 SIP account
4 XML programmable context sensitive soft keys
5 (navigation, menu) keys
9 dedicated function keys for: MESSAGE(with LED indicator), TRANSFER, HEADSET, MUTE, SEND/REDIAL, SPEAKERPHONE, VOL+, VOL-
Voice Codecs and Capabilities

Support for G.729A/B, G.711µ/a-law, G.726, G.722(wide-band), G.723,iLBC, OPUS, in- band and out-of-band DTMF(in audio, RFC2833, SIP INFO), VAD, AEC, CNG, PLC, AGC
Telephony Features

Hold, transfer, forward, 5-way conference, call park, call pickup, downloadable phonebook(XML, LDAP, up to 2000 items), call waiting, call log(up to 800 records), off-hook auto dial, auto answer, click-to-dial, flexible dial plan, hot-desking, personalised music ringtones and music on hold, server redundancy and fail-over
HD Audio

HD handset and speakerphone with support for wideband audio
Base Stand

2 angle position available (39° & 45°)
Wall Mountable (*wall mount sold separately)
QoS

Layer 2 QoS (802.1Q, 802.1P) and Layer 3 (ToS, DiffServ, MPLS) QoS
Security

User and administrator level passwords, MD5 and MD5-sess based authentication, 256-bit AES encrypted configuration file, SRTP, TLS, 802.1x media access control, secure boot
Multi-language

English, Chinese, Korean, Japanese, German, Italian, French, Spanish, Portuguese, Russian, Croatian and more
Upgrade/Provisioning

Firmware upgrade via FTP/TFTP / HTTP / HTTPS, mass provisioning using GDMS/TR069 or AES encrypted XML configuration file
Power & Green Energy Efficiency

Universal Power Supply Input 100-240VAC 50-60Hz; Output +5VDC, 600mA;PoE: IEEE802.3af Class 1, 3.84W; IEEE802.3az (EEE) (GRP2601P Only)
Temperature and Humidity

Operation: 0°C to 40°C
Storage: -10°C to 60°C
Humidity: 10% to 90% Non-condensing
Package Content

GRP2603P phone
Handset with cord
Base stand
Universal power supply(GRP2603P only)
Network cable
Quick Installation Guide
Physical

Dimension: 214mm (L) x 206mm (W) x 68mm (H) (with handset)
Unit weight: 780g
Package weight: 1090g for GRP2603P & 1140g for GRP2603P
Compliance

FCC: Part 15 Class B; FCC Part 68 HAC
CE: EN 55032; EN 55035; EN 61000-3-2; EN 61000-3-3; EN 62368-1
RCM: AS/NZS CISPR32; AS/NZS 62368.1; AS/CA S004
IC: ICES-003; CS-03
